三相振動電機 電磁設計單
振動電機電磁設計方案主要考慮電動機電能轉換機械能傳導激振力在50HZ時為大值。
* TYPE:YZS90L-4 B25:15900.00 P10: 1.86 Insulate: *
* Power: .50 (kw) P: 4. U:220. f: 50. Name: Date: *
............................................................................
* Q1=24. D1 =130.0 D2= 79.5 STATOR ROTOR *
* Q2=22. Di1= 80.0 g = .25 U1: 220. Ty= 62.19 *
* L = 105.0 Leff= 105.5 A : 1. Fd1= 20.64 *
* L1= 99.8 L2= 99.8 zf: 536.0 D = 15.00 *
* b01= 2.50 b02= 1.00 z : 67. *
* bs1= 5.5 br1= 5.00 Czn: 1. *
* Rs = 3.85 br2= 2.00 N1*d1: 1.* .80 *
* hs1= .87 br3= .00 N2*d2: 0.* .00 *
* hs2= 8.43 br4= .00 S : .50 *
* Hs0= .5 hr0= .5 Y : 5.00 *
* bt1= 5.3 hr1= 1.2 Lz: 207.1 *
* bt2= 5.8 hr2=11.0 Gcu: 1.6 .4 *
* bt3= .0 hr3= .0 R1: 5.4115 5.1935 *
* t1 =10.47 t2 =11.35 J : 6.91 4.70 / 2.57 *
* Zs1=30.00 Zs2= 30.0 Sk: 11.52 *
* hc1= 12.6 hc2= 11.4 Se: 63.79 *
* Zc= 2. Sf: .7768 *
............................................................................
* kd kp kdp zfk kc *
* stator: .9659 1.0000 .9659 517.7 1.2510 im= .6520 *
* rotor: 1.0500 ir= 1.269 *
* Tp = 62.83 Fs =1.4715 Ft =1.2500 1.3135 ix= .852 *
* Ke0= .9523 Ke1= .8777 Ft0=1.3926 i1=1.5282 3.47 *
* Fa= 339180.80 *
............................................................................
* mm*mm B L AT/cm AT i2=1.279 205.2 *
* st: 3191.4 15639. 10.6 19.30 20.49 pcu1= .1306 195.8 *
* sc: 1260.2 13458. 46.1 4.08 10.11 pcu2= .0878 131.7 *
* rt: 3169.4 15748. 12.5 21.34 23.76 pfe= .0370 55.4 *
* .0 0. .0 .00 Ps= .0065 9.8 *
* rc: 1135.5 14935. 16.3 10.39 4.65 pfw= .0122 18.4 *
* g0: 6628.8 7529. .33 197.80 pg= .2740 411.0 *
* Ikw= 2.27 a c1=.538 c2=.275 AT= 256.81 p1=1.2685 1902.8 *
* Im = 1.48 a *
............................................................................
* Eff Pf Tm Tst Ist AJ Sn *
* .7847 .8301 2.62 2.48 4.72 1535.5 .0100% *
* JB: .7100% .7900 2.30 2.30 6.00 .5599 *
............................................................................
* B0 Cm**3 w/cm**3 p Si Wi Hw *
* st: 16256.9 154.8 .038 5.54 .25 .08 2.0 *
* sc: 14467.5 464.6 .030 13.76 *
* Gfe= 13.1(Kg) PPfe= 55.4 I10= 1.75 a P10= 125.4 S0= .0015 *
............................................................................
* A1= 222.22 H1= .0265 LB= 105.0 SB= 43.7 *
* Cx=.02881 H2= .0276 Dr= 63.1 Sr= 140. *
* Ku1=1.0000 Spu1= .4165 Ku2=1.0 Spu2= .500 rb= .0463 Rb= 4.485 *
* KL1=1.0000 SpL1= .6737 KL2=1.0 SpL2= 1.119 re= .0073 Re= .708 *
* Sp1=1.0902 Sp2= 1.619 r2= .0537 R2= 5.19 *
............................................................................
* Xs1= .5815 cx Xs1s= .5100% cx Kcc= .84 *
* Xd1= 1.3231 cx Xd1s= .4962 cx XXo= .99 kax= .000 *
* Xe1= .2075 cx Xe1= .2075 cx rro= 1.02 kar= .000 *
* X1= .0609 X1s= .0370 ATst= 1533. *
* Xs2= .8791 cx Xs2s= .8584 cx BLg = 38328. Kzg = .375 *
* Xd2= 1.2821 cx Xd2s= .4809 cx Bls1= 3799. Kzs1= .990 *
* Xe2= .1131 cx Xe2= .1131 cx Bls2= 9667. Kzs2= .947 *
* Xsk= .6600 cx Xsks= .2475 cx Cs1= .03 *
* X2= .0845 X2s= .0490 Cs2= .06 *
* X= .1454 Xst= .0861 dspu1= .0027 *
* r1= .0559 r2s= .0548 dspu2= .0266 *
* R1= 5.4115 rst= .1088 spl2s= 1.1079 *
* r2= .0537 zst= .1387 sp1s= 1.0875 *
* sp2s= 1.5813 *
----------------------------------------------------------------------------
