三相力矩電動機 電磁方案解析
三相力矩電動機在設計是還要注意定轉子氣息很關鍵。氣息大了電流溫升都會高、小了輸出牛頓米會小。 電磁方案解析
TYPE:YLJ112M-8 B25:15900.00 P10: 1.86 Insulate: *
* Power: 1.50 (kw) P: 8. U:220. f: 50. Name: Date: *
............................................................................
* Q1=48. D1 =175.0 D2=119.4 STATOR ROTOR *
* Q2=44. Di1=120.0 g = .30 U1: 220. Ty= 45.59 *
* L = 95.0 Leff= 95.6 A : 1. Fd1= 15.44 *
* L1= 90.3 L2= 90.3 zf: 816.0 D = 15.00 *
* b01= 3.20 b02= 1.00 z : 51. *
* bs1= 4.1 br1= 4.10 Czn: 1. *
* Rs = 2.95 br2= 2.00 N1*d1: 1.* .95 *
* hs1= .26 br3= .00 N2*d2: 0.* .00 *
* hs2=14.24 br4= .00 S : .71 *
* Hs0= .8 hr0= .5 Y : 5.00 *
* bt1= 3.9 hr1= .9 Lz: 182.0 *
* bt2= 4.3 hr2=13.6 Gcu: 3.0 .8 *
* bt3= .0 hr3= .0 R1: 5.1328 5.0744 *
* t1 = 7.85 t2 = 8.53 J : 5.80 3.48 / 1.64 *
* Zs1=30.00 Zs2= 30.0 Sk: 8.64 *
* hc1= 10.2 hc2= 25.0 Se: 66.60 *
* Zc= 2. Sf: .7811 *
............................................................................
* kd kp kdp zfk kc *
* stator: .9659 1.0000 .9659 788.2 1.5396 im=1.1226 *
* rotor: 1.0601 ir= 1.303 *
* Tp = 47.12 Fs =1.5013 Ft =1.1721 1.6321 ix= 1.256 *
* Ke0= .9269 Ke1= .8634 Ft0=1.2789 i1=1.100%0 4.11 *
* Fa= 218210.80 *
............................................................................
* mm*mm B L AT/cm AT i2=1.290 157.6 *
* st: 2119.5 15457. 15.5 16.21 25.12 pcu1= .1737 260.6 *
* sc: 923.6 11814. 32.4 2.58 5.84 pcu2= .0873 130.9 *
* rt: 2123.7 15426. 14.8 15.76 21.29 pfe= .0319 47.8 *
* .0 0. .0 .00 Ps= .0067 10.0 *
* rc: 2259.3 4829. 12.4 1.03 .89 pfw= .0074 11.0 *
* g0: 4505.0 7272. .49 284.84 pg= .3069 460.4 *
* Ikw= 2.27 a c1=.700 c2=.700 AT= 337.99 p1=1.3030 1954.5 *
* Im = 2.55 a *
............................................................................
* Eff Pf Tm Tst Ist AJ Sn *
* .7649 .7199 2.60 2.41 4.02 1550.3 .0799 *
* JB: .7500 .6100% 2.00 1.80 5.00 .5380 *
............................................................................
* B0 Cm**3 w/cm**3 p Si Wi Hw *
* st: 16115.1 287.4 .037 10.53 .25 .08 2.0 *
* sc: 12660.6 478.1 .023 10.76 *
* Gfe= 21.6(Kg) PPfe= 47.8 I10= 2.99 a P10= 197.9 S0= .0012 *
............................................................................
* A1= 267.13 H1= .0265 LB= 95.0 SB= 45.3 *
* Cx=.03026 H2= .0276 Dr= 100.2 Sr= 168. *
* Ku1=1.0000 Spu1= .3212 Ku2=1.0 Spu2= .500 rb= .0468 Rb= 4.531 *
* KL1=1.0000 SpL1=1.3175 KL2=1.0 SpL2= 1.469 re= .0056 Re= .543 *
* Sp1=1.6387 Sp2= 1.969 r2= .0524 R2= 5.07 *
............................................................................
* Xs1= .8727 cx Xs1s= .5053 cx Kcc= .98 *
* Xd1= .7097 cx Xd1s= .4716 cx XXo= .98 kax= .000 *
* Xe1= .1950 cx Xe1= .1950 cx rro= 1.05 kar= .000 *
* X1= .0538 X1s= .0355 ATst= 1160. *
* Xs2= 1.0670 cx Xs2s= 1.0504 cx BLg = 24168. Kzg = .664 *
* Xd2= .6878 cx Xd2s= .4570 cx Bls1= 2246. Kzs1= -.612 *
* Xe2= .0992 cx Xe2= .0992 cx Bls2= 7314. Kzs2= .999 *
* Xsk= .3532 cx Xsks= .2347 cx Cs1=-8.43 *
* X2= .0668 X2s= .0557 Cs2= .00 *
* X= .1206 Xst= .0907 dspu1= .6898 *
* r1= .0530 r2s= .0549 dspu2= .0004 *
* R1= 5.1328 rst= .1034 spl2s= 1.4383 *
* r2= .0524 zst= .1376 sp1s= .9488 *
